PYS-B型西蒙斯標準型圓錐破碎機 Std. cone crusher
西蒙斯圓錐破碎機是我廠經過多年的技術開發,并引進美國先進破碎技術研制出的代表國內先進技術水平的圓錐破碎機,可完全替代進口,廣泛應用于礦山、冶金、建筑、化工、建材工業中,適于破碎堅硬、中硬等礦石及巖石。如:鐵礦石、有色金屬礦、石灰石等。
Symons cone crushers are cone crushers developed by our factory after many years of technology development and through advanced crushing technology introduced from the United States . Such cone crushers are of domestic advanced level and can completely substitute the imported ones. They are widely used in mining, metallurgy, building, chemicals, and building material industries and apply to the crushing of ores and rocks of high and medium hardness such as iron ores, nonferrous metal ores, and limestone.
型號規格 Model | 腔型 | 排料品調整范圍 | 給料口尺寸 | 生產能力 capacity | 錐大端 直徑 | 質量weight | 功率 Power | 電壓 voltage | 專用稀油潤滑站公稱流量 | |
閉口邊 | 開口 邊 | |||||||||
mm | mm | mm | t/h | mm | t | kw | V | L/min | ||
PYS-B0607 PYS-B0609 PYS-B0610 | 細型 粗型 特粗型 | 6-38 9-38 13-38 | 57 83 100 | 72 95 109 | 16-54 18-68 23-72 | 600 | 4.58 | 22 | 380 | 40 |
PYS-B0910 PYS-B0917 PYS-B0918 | 細型 粗型 特粗型 | 9-22 13-38 25-38 | 83 159 163 | 102 175 178 | 45-91 59-163 11-163 | 900 | 10.53 | 75 | 380 | 63 |
PYS-B1213 PYS-B1215 PYS-B1219 PYS-B1225 | 細型 中型 粗型 特粗型 | 9-31 13-38 19-51 25-51 | 127 156 178 231 | 131 156 191 250 | 63-168 100-200 141-308 190-317 | 1200 | 17.6 | 110 | 380 | 100 |
PYS-B1313 PYS-B1321 PYS-B1324 PYS-B1325 | 細型 中型 粗型 特粗型 | 13-31 16-38 19-51 25-51 | 109 188 216 238 | 137 210 241 259 | 109-181 132-253 172-349 236-358 | 1295 | 22.59 | 155 | 380 | 125 |
PYS-B1620 PYS-B1624 PYS-B1626 PYS-B1636 | 細型 中型 粗型 特粗型 | 16-38 22-51 25-64 38-64 | 188 213 241 331 | 209 241 269 368 | 181-327 258-417 299-635 431-630 | 1676 | 43.87 | 220 | 6000 | 200 |
PYS-B2127 PYS-B2133 PYS-B2136 PYS-B2146 | 細型 中型 粗型 特粗型 | 19-38 25-51 31-64 38-64 | 253 303 334 425 | 278 334 369 460 | 381-726 608-998 789-1270 880-1361 | 2134 | 70.13 | 315 | 6000 | 250 |
PYS-BC2127 PYS-BC2133 PYS-BC2136 PYS-BC2146 | 細型 中型 粗型 特粗型 | 19-38 25-51 31-61 38-64 | 253 303 334 425 | 278 334 369 460 | 544-1034 862-1424 1125-1814 1252-1941 | 2134 | 89.5 | 400 | 6000 | 250 |
