XYF-φ44×6 高壓釜是一種多釜高溫高壓溶出實驗裝置,釜體由不銹鋼制成,耐腐蝕,主要供冶金、化工部門對物質在100kg/㎡壓力和300℃高溫范圍內的化學反應過程進行實驗室研究使用。
Autoclave model XYF-φ44×6 is a multi-pan high-temperature and high-pressure dissolution experimental apparatus. With the body made of corrosion-resistant stainless steel, autoclave model XYF-φ44×6 is designed for laboratory investigation by chemical sectors on chemical reaction process at the pressure of 100kg/㎡ and the temperature of 300℃.
型號規格 Model | 單位 Uite | XYF-φ44×6 |
釜體容積 Kettle body volume | ml | 150 |
釜體數目 Kettle body No | 個 | 6 |
釜體壓力 Kettle body pressure | kg/ cm2 | ≤100 |
工作溫度 Temperature | ℃ | ≤300 |
加熱功率 Power | kw | 9 |
攪拌功率 Agitating power | kw | 0.55 |
外型尺寸 Overall dimension | mm | 2120×1715×2015 |
