周期式攪拌球磨機是一種濕式超細粉碎設備。適用于磁性材料、粉末冶金、涂料、油漆等物料的超細粉碎。該機體積小,重量輕,能量密度大,粉碎效率高。同時它采用定時循環磨料,保證了生產工藝的穩定。
Cycle agitating mill is a kind of wet superfine crushing equipment which applies to ultrafine crushing of materials such as magnetic materials, powder metallurgy, coating, and paint. This machine features small size, light weight, high energy density, and high crushing efficiency. Besides, it grinds materials circularly to ensure stable production process.
型號規格 Model | 單位 Uite | ZJM-1000 |
轉速(低速) Speed(Low) | r/min | 14 |
轉速(高速)Speed(High) | r/min | 57 |
****裝料量 Capacity | kg | 400 |
進料粒度 Feed size | mm | 0.074 |
出料粒度(4小時后)Output size | um | <1.5 |
主機功率Power | kw | 15/37 |
泥漿泵功率 Pump power | kw | 3 |
有效容積Volume | L | 965 |
外形尺寸 Overall dimensions | mm | 2075×1620×312 |
重量 Weight | kg | 4500 |
