螺旋分級機適用于礦石、非金屬物料進行脫水、脫介、脫泥和干濕式分級。
This classfiers suitable for dewatering,medium,drainaging amd spraying in ore clressing for medium and fine naterial wet and dry classifying in mine.
螺旋分級機是借助于固體粒大小不同,比重不同,因而在液體中的沉降速度不同的原理,細礦粒浮游在水中成溢流出,粗礦粒沉于槽底,由螺旋推向上部排出,來進行機械分級的一種分級設備,能把磨機內磨出的料粉級于過濾,然后把粗料利用螺旋片旋入磨機進料口,把過濾出的細料從溢流管排出。該機底座采用槽鋼,機體采用鋼板焊接而成。螺旋軸的入水頭、軸頭、采用生鐵套,耐磨耐用,提升裝置分電動和手動兩種。
Spiral classifier is a type of classifying equipment which realizes mechanical classification under the principle that materials settle in the liquid at different speeds due to different grain sizes and weighs: Fine grains float in the water and move out in case of overflow while coarse grains sinks to the bottom of tank which are then pushed upward by spiral. It can filter material powder grinded in the mill, and then get the coarse materials into the feed inlet of mill through the spiral slices as well as discharge the filtered fine materials out of the overflow pipe. The base of such machine is made of channel steel. Its body is welded with steel plate. Cast steel covers are used for the water inlet and spindle nose of spiral shaft which is wear-resisting and durable. The machine’s lifting device can be used manually or electronically.
型號規格 Model | 單位 Uits |
FGФ100×1200 | FGФ150×1200 | FGФ200×1650 |
螺旋尺寸 Spriral size | mm | Ф100×1200 | Ф150×1200 | Ф200×1650 |
螺距 Pitch | mm | 80 | 100 | 120 |
螺旋轉速 Speed | r/min | 18、23、30 | 18、23、30 | 18、23、30 |
槽傾斜角 Angle | (°) | 10~30 | 10~30 | 10~30 |
處理量 Capacity | kg/h | 30 | 60 | 80 |
功率 Power | kw | 0.4 0.25 | 0.6 0.4 | 1 0.6 |
電壓 Voltage | V | 220、380 | 220、380 | 220、380 |
外形尺寸Overall dimensions | mm | 1500×320×700 | 1574×320×740 | 1600×350×750 |
質量 Weight | kg | 66 | 76 | 82 |
