該機是新一代的破碎設備,能對各種物料進行快破碎,非常適用于電力、煤炭、冶金、礦山、化工、環保、地質、科研等部門。本產品由原地礦部唯一指定企業生產,執行行業標準。
1、屬環保性產品,密封設計,無粉塵溢出;清掃方便,不混樣;
2、對含水份≤18%的物料破碎效果好,不損失樣料水份,不堵料;
3、進料粒度大,出料粒度可調節;
4、生產操作過程安全可靠。
Laboratory Sealed Hammer Crusher is a new generation of crushing device and is able to quickly crush the various materials. It is suitable to be employed in electric power, coal, metallurgy, mine, chemical , environmental protection, geology, research and other sectors.The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
1. It is an environment friendly product with sealing design, no dust spillover and no blending of samples as well as easy clean-up.
2、It produces the desirable result for crushing the materials with water content ≤18% with no loss of moisture in samples and material jam free.
3、The feed size is large and the output size adjustable.
4、The process of production operation is safe and reliable.
型號 Model |
給料粒度 Feed size |
出料粒度 Output size |
生產率 Capacity |
電機功率Power | 重量 Weight |
---|---|---|---|---|---|
mm | mm | kg/h | kw | kg | |
PCF250×360 | ≤150 | ≤13-3 (可調) | 110-1800 | 3 | 300 |
PCF180×150 | ≤50 | ≤6-1 (可調) | 300-600 | 1.5 | 136 |
PCF400×150 | ≤100 | ≤6 | 800 | 1.5 | 150 |
PCF400×185 | ≤100 | ≤6 | 1200 | 3 | 180 |
PCF350×250 | ≤150 | ≤13 | ≤1000 | 3 | 190 |
PCF400×200 | ≤150 | ≤13 | 1200 | 3 | 200 |
